Manufacturer: Yuan Tai (PVI) Model: PD104SL7
Diagonal size: 10.4inch type: a-Si TFT-LCD, LCD module
Resolution: 800(RGB)×600 SVGA 133PPI pixel arrangement: RGB vertical bar
Display area: 211.2 × 158.4 mm (H×V) Appearance size:238.6 × 171 × 6.5 mm (H×V×D)
Opening area: 215.4 × 162.6 mm (H×V) surface treatment: matte
Display brightness: 230 cd/m² (Typ.) Contrast: 400:1 (Typ.) (Transmission)
Recommended viewing angle: 6 o'clock Response time: 15/25 (Typ.)(Tr/Td) ms
Viewing angle:45/45/15/40 (Typ.)(CR≥10) Display mode: TN, normally white display, transmissive
Support color:262K light source type: 1 pcs CCFL, 20K hours, no driver
Touch technology: No touch Application products: Industrial and subway gate display
Voltage supply: 3.3V (Typ.)(VCC) Interface type:60 pins LVDS (1 ch, 6-bit), connector, 14 pins
Operating temperature:0 ~ 60 °C Storage temperature: -20 ~ 70 °C
Packing feature: 10 pcs/carton weight:310/320g (Typ./Max.)
Packing box size: 530×295×230 mm (L×W×H)
